| Type |
| Server |
| Product Form Factor |
| Tower - 5U |
| Built-in Devices |
| 1 x rear fan |
| Embedded Security |
| Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
| 1-way |
| Internal Bays Qty |
| 3 |
| Localization |
| Region: North America |
|
| |
| CPU |
| Intel Xeon E-2324G |
| Clock Speed |
| 3.1 GHz |
| Max Turbo Speed |
| 4.6 GHz |
| Number of Cores |
| Quad-Core |
| CPU Qty |
| 1 |
| Max CPU Qty |
| 1 |
| CPU Socket |
| LGA1200 Socket |
| Chipset Type |
| Intel C256 |
|
| |
| Installed Size |
| 8 MB |
| Cache Per Processor |
| 8 MB |
|
| |
| Installed Size |
| 16 GB (installed) / 128 GB (max) |
| Technology |
| DDR4 SDRAM - ECC |
| Effective Memory Speed |
| 3200 MHz |
| Rated Memory Speed |
| 1600 MHz |
| Form Factor |
| DIMM 288-pin |
| Slots |
| 4 (total) / 3 (empty) |
| Features |
| Unbuffered |
| Configuration Features |
| 1 x 16 GB |
|
| |
| Type |
| No HDD |
|
| |
| Type |
| 1 x SATA |
|
| |
| Type |
| No optical drive |
|
| |
| Monitor Type |
| None. |
|
| |
| Graphics Processor |
| Intel UHD Graphics P750 shared video memory (UMA) |
| Video Interfaces |
| DisplayPort |
|
| |
| Ethernet Controller |
| Intel I219-LM |
| Data Link Protocol |
| Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
| Wake on LAN (WoL), Teaming support, Intel Active Management Technology (AMT) 15 |
| Compliant Standards |
| DASH 1.1 |
|
| |
| Bays |
| 1 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots |
| 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode) |
| Interfaces |
| 1 x USB-C 3.2 Gen 2 (1 in front) ¦ 2 x USB 3.2 Gen 2 (2 in front) ¦ 6 x USB 3.2 Gen 1 (2 front, 4 rear) ¦ 2 x DisplayPort ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x serial ¦ 1 x audio line-out |
|
| |
| Theft/Intrusion Protection |
| Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
| Kensington security slot |
| Compliant Standards |
| TUV GS, BSMI, IEC 60950-1, GB 17625.1, VCCI Class A, GB 4943.1, INMETRO, NOM-019, EK1-ITB2000, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TP TC 004/2011, HJ 2507-2011, Energy-Related Products (ErP) Lot 9, TP EAC 037/2016, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135, CSA C22.2 No. 62368-1, CMIM |
|
| |
| Device Type |
| Power supply |
| Voltage Required |
| AC 100-240 V (50/60 Hz) |
| Power Provided |
| 300 Watt |
| 80 PLUS Certification |
| 80 PLUS Gold |
| Efficiency |
| 90% |
|
| |
| OS Provided |
| No operating system |
|
| |
| Carbon Footprint |
| 5330 kg carbon emissions |
|
| |
| Service & Support |
| Limited warranty - 3 years - on-site - response time: next business day |
|
| |
| Width |
| 6.7 in |
| Depth |
| 12.4 in |
| Height |
| 14.8 in |
| Weight |
| 20.72 lbs |
|
| |
| Shipping Width |
| 11 in |
| Shipping Depth |
| 16.5 in |
| Shipping Height |
| 21.3 in |
|
| |
| Min Operating Temperature |
| 50 °F |
| Max Operating Temperature |
| 95 °F |
| Humidity Range Operating |
| 8 - 80% |
