| Device Type |
| Firewall |
| Bundled Services |
| 1 year License Bundle |
| Width |
| 10.7 in |
| Depth |
| 7.4 in |
| Height |
| 1.4 in |
| Weight |
| 3.35 lbs |
|
| |
| Form Factor |
| Rack-mountable |
| Ports Qty |
| 8 |
| Connectivity Technology |
| Wired |
| Data Link Protocol |
| Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Network / Transport Protocol |
| IPSec, DDNS, SMTP, POP3, FTP, HTTP, HTTPs |
| Remote Management Protocol |
| Telnet, SSH, SNMP 1, SNMP 2c, SNMP 3, DHCP |
| Cloud-Managed |
| Yes |
| Performance |
| SPI firewall throughput: 5 Gbps ¦ VPN throughput: 1.2 Gbps ¦ IPS throughput: 2 Gbps ¦ Anti-malware throughput: 1.5 Gbps ¦ Unified Threat Management (UTM) throughput: 1.5 Gbps |
| Capacity |
| Concurrent TCP sessions: 600000 ¦ Concurrent IPSec VPN tunnels: 100 ¦ Gateway to gateway IPSec VPN Tunnels: 50 ¦ Concurrent SSL VPN users: 50 ¦ Virtual interfaces (VLANs): 32 ¦ Concurrent logins: 200 |
| Features |
| Anti-malware protection, Application Patrol, device insight, Intrusion Prevention System (IPS), sandboxing, SecuReporter, Web Filtering, VPN support, 2-factor authentication, SSL inspection, routing, bridge mode, Stateful Packet Inspection (SPI), NAT support, ALG support, DoS attack prevention, content filtering, Source & Destination Address, DNS filtering, IP address filtering, CTIRU (Counter-Terrorism Internet Referral Unit) support, Perfect Forward Secrecy (PFS), Pre-Shared Key (PSK), IPSec NAT-Traversal (NAT-T), Dead Peer Detection (DPD), SNAT support, DHCP client, DHCP server, DHCP relay, WAN load balancing, WAN failover, dual firmware images, Syslog support, traffic monitoring |
| Encryption Algorithm |
| IKEv2, SSL, TLS 1.3, DES, Triple DES, 256-bit AES, MD5, SHA-1, 512-bit SHA-2 |
| Authentication Method |
| X.509 certificates |
|
| |
| Interfaces |
| 2 x 2.5 GBase-T - RJ-45 ¦ 6 x 1000Base-T - RJ-45 ¦ 1 x USB 3.0 - Type A ¦ 1 x console - RJ-45 |
|
| |
| Cables Included |
| 1 x RJ-45 to RS-232 cable |
| Compliant Standards |
| FCC Part 15 Class B, EMC Class B, RCM Class B, BSMI, EN 62368-1 |
|
| |
| Power Device |
| External power adapter |
| Voltage Required |
| DC 12 V |
| Power Consumption Operational |
| 22 Watt |
|
| |
| Shipping Width |
| 16.8 in |
| Shipping Depth |
| 9.7 in |
| Shipping Height |
| 2.9 in |
| Shipping Weight |
| 5.36 lbs |
|
| |
| Min Operating Temperature |
| 32 °F |
| Max Operating Temperature |
| 104 °F |
| Humidity Range Operating |
| 10 - 90% (non-condensing) |
